Ortofon 2M Red, 2M Red Verso and 2M Red PnP
The 2M Series of cartridges is designed for precise and accurate retrieval of the information in the record groove. Our philosophy is to play the record sound as accurate as possible, without coloring the sound
The name 2M was selected among several ideas. We wanted a modern name that would be easy to pronounce and to remember, and therefore an alpha numerical name was chosen. 2M means MM, which is the abbreviation for moving magnet.
The 2M series of cartridges feature Ortofon’s trademark split pole pins, an invention that enables moving magnet cartridges to have a flat frequency response, as with a moving coil cartridge. Split pole pins were invented by Ortofon, and were originally presented in the 500 series and Super OM series.
We have optimized the design for ease of mounting the cartridge, weight and size to fit the most common turntables at the market today. 2M Series provides excellent compatibility in an assortment of playback systems and with a wide variety of phono preamps. To find the recommended Ortofon replacement cartridge for your turmtable/tonearm please visit our Replacement cartridges selector ».
The new 2M Red Verso is an alternative product for bottom mount tonearms
The 2M Red Series features:
- an improved engine, which provides an increased output of 5.5mV
- a tipped Elliptical diamond and split pole pins with a copper wire
2M Red Plug and Play model
The new 2M headshell is a practical and elegant solution for our customers who wish direct and easy mounting and replacement on their tonearm. The combination of 2M Headshell and 2M Series cartridge adds unique distinction to the turntable!
2M Headshell features:
- Universal mount fitting a wide range of tonearms. NB: on Technics models please use the auxiliary weight which is vital in this case.
- The headshell body is manufactured from a special compound used for Medical industry, ensures high rigidity while reducing unwanted vibration
- Elegant hi-tech design
- Length 52mm. Headshell with a 2M cartridge pre-mounted provides correct Baerwald alignment with Ortofon TA-110/210, likewise with the major part of tonearms with universal mount
- Weight 16,9g, weight with a 2M cartridge pre-mounted 23g
- Exclusive plug-and-play solution
NB: The 2M headshell will be available in 2M PnP configuration (2M cartridge pre-mounted on the 2M headshell)
|
Technical data 2M Red / 2M Red Verso |
||||||||||
| Output voltage at 1000 Hz, 5cm/sec. | 5,5 mV | |||||||||
| Channel balance at 1 kHz | 1,5 dB | |||||||||
| Channel separation at 1 kHz | 22 dB | |||||||||
| Channel separation at 15 kHz | 15 dB | |||||||||
| Frequency range at – 3dB | 20-22.000 Hz | |||||||||
| Frequency response | 20-20.000 Hz + 3 / – 1 dB | |||||||||
| Tracking ability at 315Hz at recommended tracking force | 70 µm | |||||||||
| Compliance, dynamic, lateral | 20 µm/mN | |||||||||
| Stylus type | Elliptical | |||||||||
| Stylus tip radius | r/R 8/18 µm | |||||||||
| Tracking force range | 1,6-2,0g (16-20 mN) | |||||||||
| Tracking force, recommended | 1,8 g (18 mN) | |||||||||
| Tracking angle | 20° | |||||||||
| Internal impedance, DC resistance | 1,3 kOhm | |||||||||
| Internal inductance | 700 mH | |||||||||
| Recommended load resistance | 47 kOhm | |||||||||
| Recommended load capacitance | 150-300 pF | |||||||||
| Cartridge colour, body/stylus | Black/Red | |||||||||
| Cartridge weight | 7,2 g | |||||||||
| Replacement stylus unit | 2M Red (interchangeable with 2M Blue) | |||||||||
| Stylus protection guard | 2M Red | |||||||||
|
||||||||||
|
How to replace M2,0 mm screws on 2M Red Verso |
||||||||||
|
||||||||||
